Quote coordination for a metal stamping press supplier starts with one shared envelope: material and thickness, required load and the millimetres above bottom dead center where it is applied, working energy in joules, stroke, intended SPM with the production die, die height, bolster size, permitted die mass in kg, connected load in kW and the three-phase supply. Metal Stamping Press Sourcing lines those inputs so metal stamping press manufacturers reply on included items rather than catalog headlines that omit inclusions. We remain an independent sourcing partner; named plants answer feasibility. Brochure no-load SPM that omits feed timing is not a comparable duty cycle. Ask each shortlist plant whether the die fits the bolster and die-mass envelope before treating two quotes as interchangeable.

Service stage and responsibilities

Supplier shortlist

Decision context

Industry dispute: machine list price versus installed project cost. A lower press figure can still raise total cost when tooling, feeders, freight and SAT labor are billed later. Compare like-for-like inclusions; do not treat an unnamed discount percentage as evidence. Read feed and die interface notes before accepting a demonstration that only counts empty-slide cycles.

A second dispute is single machine versus integrated line. If the buyer needs a stamping cell, decoiler, straightener, feeder, lubrication and scrap removal must sit on the same inclusion map. If only the press is in scope, write that boundary so metal stamping press manufacturers do not fill gaps with silent extras. We do not claim a factory audit; we ask for named documents.

Supplier shortlist
Decision point	Evidence or question
Supplier shortlist: Sample run	Require each bidder to state force at the rating point, working energy for the full stroke, and the slide motion used with a representative die. Empty-cycle SPM is not the sample run.
Site readiness	Collect pit or floor load, compressed air demand, cooling if the drive needs it, PLC interface names and feed-line footprint. Site work stays separately quoted unless the bid drawing includes it.
Owner acceptance	Name who signs FAT and SAT, which run length counts, and who supplies the production die. Owner acceptance is a contract step, not a website certificate.

Assumptions every metal stamping press supplier should quote in writing: coil or blank size, lubrication, off-centre loading if expected, and whether tooling protection and part detection are included. If a plant cannot confirm die mass against the listed envelope, keep that factory off the shortlist until a drawing arrives. Certificates such as CE or UL, when relevant to destination, are requested as supplier documents for the named machine, not as a claim that one mark covers the whole cell.

Work envelope and footprint belong beside electrical data. A gap-frame press that fits the shop door may still fail if the bolster is smaller than the die shoe. Positioning tolerance of the slide and the feeder pitch are separate checks. We circulate one brief, return comparable quotations, and leave engineering acceptance between you and the equipment supplier. No existing quotation is required to start.

Interface	Buyer input
Electrical	Voltage, phase and frequency; connected load in kW for the press and any quoted feeder.
Utilities	Compressed air for clutch or counterbalance; lubrication; extraction if oil mist is expected.
Controls	PLC interface names, feeder release timing signals, and whether die-protection sensors are plant-side.
